Aluminium Panel Board Lugs Dual Rated
| Catalog Number |
Figure Number |
Wire Range |
Bolt Size |
C | E | F | G | H | J | K | R | T | Hex Size |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| PB2-300 |
1 |
300kcmil-6 |
5/16 |
21/64 |
1 |
3 |
15/32 |
1 |
– |
5/16 |
2 |
2-5/16 |
5/16 |
| PB2-500 |
2 |
500kcmil-4/0 |
1/4 |
9/32 |
1-11/16 |
2-29/32 |
1/4 |
1-7/16 |
11/16 |
5/8 |
2-3/8 |
1-27/64 |
3/8 |
| PB2-600 |
4 |
600kcmil-2 |
3/8 |
13/32 |
2-11/32 |
4-29/32 |
3/8 |
1-1/2 |
1-3/8 |
3/4 |
3 |
3-29/64 |
1/2 |
| PB3-600 |
6 |
600kcmil-2 |
3/8 |
13/32 |
2-11/32 |
4-29/32 |
3/8 |
2-15/32 |
1-3/8 |
3/4 |
3 |
3-29/64 |
1/2 |
| PB4-600 |
8 |
600kcmil-2 |
3/8 |
13/32 |
2-11/32 |
4-29/32 |
3/8 |
2-15/32 |
1-3/8 |
3/4 |
3 |
3-29/64 |
1/2 |
| PB2-750 |
4 |
750kcmil-1/0 |
3/8 |
13/32 |
2-11/32 |
4-29/32 |
3/8 |
1-11/16 |
1-3/8 |
3/4 |
3 |
3-29/64 |
1/2 |
| PB4-750 |
8 |
750kcmil-1/0 |
3/8 |
13/32 |
2-11/32 |
4-29/32 |
3/8 |
2-5/8 |
1-3/8 |
3/4 |
3 |
3-29/64 |
1/2 |
| PB3-600-2N |
5 |
600kcmil-2 |
1/2 |
9/16 |
3-1/8 |
5-11/16 |
3/8 |
2-15/32 |
1-3/4 |
3/4 |
3 |
3-29/64 |
1/2 |
| PB2-600-2N |
3 |
600kcmil-2 |
1/2 |
9/16 |
3-1/8 |
5-11/16 |
3/8 |
1-1/2 |
1-3/4 |
3/4 |
3 |
3-29/64 |
1/2 |
| PB2-750-2N |
3 |
750kcmil-1/0 |
1/2 |
9/16 |
3-1/8 |
5-11/16 |
3/8 |
1-11/16 |
1-3/4 |
3/4 |
3 |
3-29/64 |
1/2 |
| PB2-600-2N |
7 |
600kcmil-2 |
1/2 |
9/16 |
3-1/8 |
5-11/16 |
3/8 |
2-15/32 |
1-3/4 |
3/4 |
3 |
3-29/64 |
1/2 |
| PB2-750-2N |
7 |
750kcmil-1/0 |
1/2 |
9/16 |
3-1/8 |
5-11/16 |
3/8 |
3-1/16 |
1-3/4 |
3/4 |
3 |
3-29/64 |
1/2 |
